LCR-DH Huihong Series Online Soft Starter Panel

1.Brand new appearance design, bottom angle raised by 5cm, access the cable easily.

2.Equipped with LCD screen display and double digital display key board, so the voltage and current observation is more convenient.

3.Adopt 64-bit singlechip and core algorithm for the LCR-DH Huihong series online soft starter control cabinet, and it has big driving torque and can deal with overloaded equipment more easily.

4.Control power supply for the LCR-DH Huihong series control cabinet is AC100-500V voltage design, so it is more stable and reliable, and can adapt to more fields.

5.It is with the motor full time super protection function, such as input and output missing, under-load, over-voltage, instantaneous over-current, three-phase imbalance blocking, phase sequence detection, start timeout, frequent start and thyristor overheating.

6.Built-in standard 485 communication for LCR-DH series control cabinet, 0-20 mA or 4-20 mA

7.Built-in standard 3-way programmable relay output for LCR-DH series control cabinet, so it can achieve custom output of many functions (see internal parameters for details).

8.Built-in 1 pc D1 programmable terminal for this series control cabinet, thus it can realize more functional applications, such as fault reset (NO), instantaneous stop protection and external fault (NC) water shortage protection (NO), power-on startup ( two wires start-stop control ) and jog control.

9.LCR-DH Huihong series control panel Includes shell cloud function, and can support mobile and computer terminal parameter setting and start-stop control.
